Chapter 5: Configuring the Router
5.15.2 Host
Choose “Access Control ― Host,” then you can view and set a Host list in the screen. The host list is necessary for the Access
Control Rule.
Figure 5-82. Host Settings.
• Description—Displays the description of the host and this description is unique.
• Address Info—Displays the information about the host. It can be IP or MAC.
• Edit—Modify or delete an existing entry.
Click the Delete Selected button to delete the selected entries in the table.
To add a new entry, follow the steps below.
1. Click the Add New button.
2. In the Mode field, select IP Address or MAC Address.
2a. If you select IP Address, the screen shown is Figure 5-83.
• In the Description field, create a unique description for the host (e.g. Host_1).
• In the IP Address field, enter the IP address.
2b. If you select MAC Address, the screen shown is Figure 5-84.
• In the Description field, create a unique description for the host (e.g. Host_1).
• In the MAC Address field, enter the MAC address.
3. Click the Save button to complete the settings.
Figure 5-83. Add or Modify a Host Entry.
