Blackmagicdesign Studio Camera User Manual

Blackmagic
Studio Camera
Blackmagic
Studio Camera 4K
Blackmagic Micro
Studio Camera 4K
1080p25 1080p25 1080p25
1080p29.97 1080p29.97 1080p29.97
1080p30 1080p30 1080p30
1080p50 1080p50 1080p50
1080p59.94 1080p59.94 1080p59.94
1080p60 1080p60 1080p60
– 2160p23.98 2160p23.98
– 2160p24 2160p24
– 2160p25 2160p25
– 2160p29.97 2160p29.97
– 2160p30 2160p30
– 2160p50 –
– 2160p59.94 –
– 2160p60 –
Audio Settings
To adjust audio input and audio monitoring settings on your Blackmagic Studio Camera,
pressthe ‘menu’ button and select the microphone icon to the left of the display. Use the
menunavigation buttons to highlight menus and use the ‘set’ button to confirm your selection.
Automatic Gain Control
Blackmagic Micro Studio Camera 4K features an automatic audio gain control setting that lets
camera adjust the audio recording levels. It automatically reduces the audio gain levels if the
input level gets too loud and subtly raises it if it is too low.
Audio settings – Blackmagic Studio Camera.
2121Settings

Blackmagicdesign Studio Camera Specifications

General

Power	12V DC
Frame Rates	23.98, 24, 25, 29.97, 30
Audio Input	2 x XLR
Video Output	HDMI, 6G-SDI, 3G-SDI
Power Input	12V DC
Connections	XLR
