Blackmagicdesign Studio Camera User Manual

Group ID Parameter Type Index Minimum Maximum Interpretation
Video
1.9 Recording format int16
[0] = file
frame rate
– –
fps as integer
(eg 24, 25, 30, 50, 60, 120)
[1] = sensor
frame rate
– –
fps as integer, valid when
sensor-off-speed set
(eg 24,25, 30, 33, 48, 50,
60, 120), no change will
beperformed if this value
is set to 0
[2] = frame width – – in pixels
[3] = frame height – – in pixels
[4] = flags
– – [0]=file-M-rate
– –
[1]=sensor-M-rate,
valid when sensor-
off-speed-set
– – [2]=sensor-off-speed
– – [3]=interlaced
– – [4]=windowed mode
1.10 Set auto exposure mode int8 – 0 4
0=Manual Trigger,
1=Iris,
2=Shutter,
3=Iris + Shutter,
4=Shutter + Iris
Audio
2.0 Mic level fixed16 – 0 1
0.0=minimum,
1.0=maximum
2.1 Headphone level fixed16 – 0 1
0.0=minimum,
1.0=maximum
2.2 Headphone program mix fixed16 – 0 1
0.0=minimum,
1.0=maximum
2.3 Speaker level fixed16 – 0 1
0.0=minimum,
1.0=maximum
2.4 Input type int8 – 0 2
0=internal mic,
1=line level input,
2=low mic level input,
3=high mic level input
2.5 Input levels fixed16
[0] ch0 0 1
0.0=minimum,
1.0=maximum
[1] ch1 0 1
0.0=minimum,
1.0=maximum
2.6 Phantom power boolean – – –
true = powered,
false = not powered
Output
3.0 Overlay enables
uint16
bit field
– – –
bit flags: [0] = display status,
[1] = display frame guides
Some cameras don't allow
separate control of frame
guides and status overlays.
3.1
Frame guides style
(Camera 3.x)
int8
[0] = frame
guides style
0 8
0=off, 1=2.4:1, 2=2.39:1,
3=2.35:1, 4=1.85:1, 5=16:9,
6=14:9, 7=4:3
227227Informationen für Entwickler

Blackmagicdesign Studio Camera Specifications

General

Power	12V DC
Frame Rates	23.98, 24, 25, 29.97, 30
Audio Input	2 x XLR
Video Output	HDMI, 6G-SDI, 3G-SDI
Power Input	12V DC
Connections	XLR
