24
4
Enter the gataway IP address if a product is outside the local network (LAN).
5
Enter the address of the primary DNS in order to assign a domain name.
6
Enter the domain name extension in order to access the product’s web server from the DNS.
e.g. if the name of the product is “Netsilon” (see Chapter 4.1 Start-up)
Example of access to the web server using the domain name:
4.4.2. ETHERNETexpansioncard(ref.907920)
The network expansion card can be used to synchronise several separate Ethernet networks.
To configure a network output, see Chapter 4.4.1 ConguringtheETH0Ethernetport.
The mechanical installation is performed in our factory. For any subsequent installation, refer to the expansion card
installation guide available from www.bodet-time.com.
The labels containing the MAC address for each port are placed in line with the RJ45 connector
http://netsilon.test.local
