Bodet NETSILON 7 - Time Distribution; AFNOR Expansion Card (Ref. 907940)

40
4.7 Timedistribution
Option cards can be selected in two ways:
- In dynamic mode: hover the mouse over the desired expansion card then click. The menu dedicated to this option
card is shown on the screen.
- Click the button of the desired expansion card.
4.7.1. AFNORexpansioncard(ref.907940)
The AFNOR expansion card enables wired time distribution (AFNOR / IRIB B 127 standard) or by DHF using the
DHF transmitter.
the2outputscantransmitadifferenttime(differenttimezone).
To configure the AFNOR output, follow these steps:
1) TIME menu > Outputs > Slot B: Afnor:
2) Configure an output by clicking , and the following window will appear:
3) Select the time zone which will be transmitted via output A and/or B of the AFNOR expansion card.
4) Enable the output using the button, then save.
