Handling of the Objects
16.5 Actual Value Display of Profibus Data
For analysis purposes,
DP-Master OUT 281
and
DP-Master IN 284 are displayed in the data
transmitted via the Profibus under the actual value parameters.
The parameters are situated in the "Actual values\Actual values frequency inverter"
menu of
the VPlus PC-Software.
In these parameters, the data transmitted via the Profibus are displayed in a proc
essed and
comprehensible form. The contents of the process data channel with control word,
reference value
etc. are permanently updated. As the communication chan
nel has the contents zero in idling and
transmission is very fast, the contents of the communication channel are stored on the device side
and displayed in the actual value parameters with every transmission.
The displayed content of the communication channel does not correspond to the cur
rent state, but the
last transmission.
Handling of the Objects
The following diagrams show the display for a configuration setting with PPO2. The PPO2 includes the
communication PKW channel for parameter access and 6 PZD objects with default settings for In-
PZD
objects.
Actual Value
Parameter
DP-Master OUT
281
= C: a nnnn I: iiii 00 V: wwwwww cccc rrrr xxxx xxxx xxxx xxxx
Meaning
C: a a
= request identification
hexadecimal
C: nnnn nnnn = parameter number decimal
I: iiii iiii = index hexadecimal
V: ww..w ww..w = parameter value decimal (with sign in front)
cccc PZD1 = control word hexadecimal
rrrr PZD2 = reference value hexadecimal, relative to
0x4000 = 100% of the reference value
xxxx PZD3 user defined
hexadecimal
xxxx PZD4 user defined
hexadecimal
xxxx PZD5 user defined
hexadecimal
xxxx PZD6 user defined
hexadecimal
Actual Value
Parameter
DP-Master IN
284
= C: a nnnn I: iiii 00 V: wwwwww cccc ssss xxxx xxxx xxxx xxxx
Meaning
C: a a
= reply identification
hexadecimal
C: nnnn nnnn = parameter number decimal
I: iiii iiii = index hexadecimal
V: ww..w ww..w = parameter value decimal (with sign in front)
cccc PZD1 = state word hexadecimal
ssss PZD2 = actual value hexadecimal, relative to
0x4000 = 100% of the reference value
xxxx PZD3 = abs. current hexadecimal, relative to 0x4000 =
100% of the rated motor current
xxxx PZD4 = active current hexadecimal, relative to 0x4000 =
100% of the rated motor current
xxxx PZD5 = Warning hexadecimal (bit-coded)
xxxx PZD6 = Fault hexadecimal
