Probus DP V1 Agile 06/201056

Handling of the Objects

Example:

Actual Value

Parameter

DP-Master OUT

281

= C: 6 480 I: 0300 V: -005500 000F 2000 0000 0000 0000 0000

Meaning

C: 6 Request identification = 6 (Read parameter value Array)

C: 480 Parameter number = 480 (Fixed frequency 1)

I: 0300 Data set = 3

V: -005500 Parameter value = -5500 = -55.00 Hz (0xFFFEA84 hexadecimal)

000F Release command (transition 4)

2000 Set point = 0x2000 = 50% of the reference value

0000 not used

Actual Value

Parameter

DP-Master IN

284

= C: 5 480 I: 03 00 V: -005500 06A7 2000 1147 0CCC 0800 0000

Meaning

C: 5 Reply identification = 5 (Transmit parameter value long Array)

C: 480 Parameter number = 480 (Fixed frequency 1)

I: 03 00 Data set = 3

V: -005500 Parameter value = -5500 = -55.00 Hz (0xFFFEA84 hexadecimal)

06A7 State = 0x27 "Operation enabled“ (Bit 0 ... 6),

Warning 2 present (Bit 15 = 1 threat of fault switch-off),

reference value reached (Bit 10 = 1),

remote operation (Bit 9 = 1),

Warning present (Bit 7 = 1)

2000 Actual value = 0x2000 = 50% of the reference value

1147 Abs. current = 0x1147 = 27% of the rated motor current

0CCC Active current = 0x0CCC = 20% of the rated motor current

0800 Warning, Warning motor temperature available

0000 Fault, no fault pending
