bora M Pure - Cleaning the Air Guiding Housing; Replace the Activated Charcoal Filter

Cleaning and maintenance
EN
106 bora.com
u
Check whether any liquid has gathered in the base of
the air guiding housing.
u If necessary, wipe the liquid up from the housing
base from above through the inlet opening using a
sponge or cloth.
u Clean the air guiding housing.
u To dry the activated charcoal filter and duct parts,
switch on the cooktop extractor at a minimum power
level of 5.
T After 120 minutes the cooktop extractor will
automatically switch off and the automatic after-run
function will be started.
7.5
Cleaning the air guiding
housing
The air guiding housing can be found on the bottom of
the cooktop inside the floor unit.
Grease particles and limescale residues can settle on
the surface of the air guiding housing. For this reason,
regular cleaning is essential.
Opening the air guiding housing
u
Remove the air inlet nozzle and stainless steel grease
filter.
u Remove the filter replacement cover (see figure).
u Hold the housing base with one hand.
u Release the 6 locks around the edge of the base.
u Remove the housing base.
u Clean the air guiding housing and the housing base
with a mild cleaning agent.
1
2
345
Fig.7.3
Air guiding housing
[1] Air guiding housing
[2] Housing base
[3] Spigot
[4] Sealing groove
[5] Lock
Closing the air guiding housing
u
Position the housing base under the air guiding
housing with the help of the 3 spigots.
u Push the housing base upwards into the sealing
groove.
u Close the 6 locks.
u Check that the housing base is positioned correctly.
u Insert the filter replacement cover (see figure).
u Check that the filter replacement cover is positioned
correctly.
u Insert the stainless steel grease filter and the air inlet
nozzle.
7.6
Replace the activated
charcoal filter
An activated charcoal filter will only be fitted with the
stainless steel grease filter if the cooktop extractor is
used in recirculation mode. The activated charcoal filter
absorbs cooking odours that arise during cooking.
