Bosch 4100XC - Unpacking And Checking Contents

15
To avoid injury from un-
expected starting or elec-
trical shock during unpacking and setting
up, do not plug the power cord into a source
of power. This cord must remain unplugged
whenever you are working on the table saw.
If any parts are missing,
do not attempt to assem-
ble the table saw, plug in the power cord or
turn the switch on until the missing parts
are obtained and are installed correctly.
Model 4100XC table saw is shipped complete
in one carton.
Separate all parts from packing materials and
check each one with the illus tration and the
list of loose parts to make certain all items
are accounted for before discarding any pack-
ing material (Fig. 2).
NOTE: Remove styrofoam block 10 (for ship-
ping purpose only) located between the table
and motor (Fig. 3). You may cause damage to
the blade elevation system if trying to raise
blade if styrofoam is not removed.
10
Unpacking And Checking Contents
TABLE OF LOOSE PARTS
ITEM DESCRIPTION QTY.
1 Table saw assembly 1
2 Rip fence 1
3 Table insert 1
4 Barrier guard assembly 1
5 Anti-kickback device 1
6 Miter gauge 1
7 Push stick 1
8 Thin workpiece fence 1
9 Bottom Screen 1
10
Styrofoam block (for shipping
purposes only)
1
1
9
7
3
4
6
5
8
2
Fig.2
Fig. 3
