16
Tools Needed For Assembly
Disconnect plug from power source before performing any assembly, adjustment
or repair to avoid possible injury.
FLAT SCREWDRIVER
COMBINATION SQUARE
PHILLIPS SCREWDRIVER
10 mm WRENCH OR
ADJUSTABLE WRENCH
SHOULD BE NO GAP OR OVERLAP
HERE WHEN SQUARE IS FLIPPED
OVER IN DOTTED POSITION.
COMBINATION SQUARE MUST BE TRUE
DRAW LIGHT LINE ON
BOARD ALONG THIS EDGE.
STRAIGHT EDGE OF BOARD
3/4" THICK. THIS EDGE
MUST BE PERFECTLY
STRAIGHT.
