Page #38 background image
password = password
port = default is 554 (this is optional)
channel = channel number 1..16
subtype = 0 or 1 (1
st
or 2
nd
stream)
Notice!
Reboot
The system always needs to reboot if any of the above ports are changed. Make sure the port
values here do not conflict.
Streaming
Choose your preferred Live Video Stream Buffering:
Realtime
Balanced
Network optimized
Custom - set here your preferred streaming buffer (minimum 200 ms, maximum 2000 ms,
default 500 ms)
Add
The buffer size increases from 'Realtime' to 'Balanced' to 'Network optimized'. 'Realtime' uses
a minimum buffer to minimize latency. If your video stream has a high bit-rate, the video may
not run smooth in live mode. To get a smoother video, you can increase the buffer by selecting
'Balanced' or 'Network optimized'. But this will increase the latency.
DDNS
Make sure the recorder is connected to the open internet, before you configure the DDNS
service.
Go to your router that connects your recorder to the internet and forward these
communication ports: HTTPS, RTSP and TCP. In the recorder, you can find and configure
these ports in the menu: Network – Connection – Port. If you plan to connect through HTTP as
well, forward the HTTP port in your router. Bosch advises to use only HTTPS connections for
a higher security. Read your router manual for instructions to forward ports to a device.
Use these steps to configure DDNS:
1. Select the ‘Enable’ box.
2. Select DDNS provider(s) from the drop-down menu. More DDNS types can be used at the
same time; you only need to select the required type. These providers are supported:
Bosch remote portal (see Notice)
NO-IP DDNS
Dyndns DDNS
8.2.2
38 en | Settings
DIVAR 2000 / DIVAR 3000 / DIVAR
5000
2016.09 | v1.0 | AM18-Q0717 Operation Manual Bosch Security Systems

Table of Contents

Questions and Answers:

Question and Answer IconNeed help?

Do you have a question about the Bosch DIVAR 3000 and is the answer not in the manual?

Bosch DIVAR 3000 Specifications

General IconGeneral
AC input voltage100 - 240 V
AC input frequency50 - 60 Hz
Power consumption (max)20 W
Storage temperature (T-T)0 - 93 °C
Operating temperature (T-T)0 - 40 °C
Storage relative humidity (H-H)0 - 95 %
Operating relative humidity (H-H)-40 - 70 %
Sustainability certificatesRoHS
CertificationEMC, LVD, UL, cUL, CAN/CSA, BIS, RCM, ACMA EMC, CE, FCC
On/off switchYes
Product colorBlack, Silver
Rack capacity-
Bit rate24000 Kbit/s
Display modesLive view
Playback modesFast play, Forward, Frame by Frame, Reverse, Slow play
Input bandwidth320 Mbit/s
Number of users128 user(s)
Recording modesManual, Schedule, Stop
Output bandwidth256 Mbit/s
Maximum resolution3840 x 2160 pixels
Alarm input channels16
Video input channels16 channels
Alarm output channels3
Supported resolutions3840×2160, 1920×1080, 1280×1024, 1280×720, 1024×768, 970x576, 704x576, 352x576, 352x288, 176x144, 960x480, 704x480, 352x480, 352x240, 176x120
Video recording modes720p, 1080p
Video formats supportedH.264, H.265, M-JPEG
RS-232 ports1
Audio RCA inputs4
Networking standardsIEEE 802.3
USB 2.0 ports quantityUSB 2.0 ports have a data transmission speed of 480 Mbps, and are backwards compatible with USB 1.1 ports. You can connect all kinds of peripheral devices to them.
Ethernet LAN data rates10, 100, 1000 Mbit/s
Ethernet LAN (RJ-45) ports2
Supported network protocolsHTTP, HTTPS, TCP/IP, IPv4/IPv6, UPnP, RTSP, UDP, SMTP, NTP, DHCP, DNS/DDNS, IP Filter, PPPoE, FTP
Copper ethernet cabling technology10BASE-T, 100BASE-T, 1000BASE-T
Wi-FiNo
HDD capacity- GB
HDD interfaceSerial ATA
Maximum storage capacity6 TB
Mobile operating systems supportedAndroid, iOS
Weight and Dimensions IconWeight and Dimensions
Depth323 mm
Width375 mm
Height53 mm
Weight4130 g
