De-bounce time: Set here a timer for how long the detect alert should stay active after it is
first activated (default is 5 seconds). During this time, the system will activate the alarm
display, alarm output, tour, PTZ, snapshot, channel recording and buzzer (if they are all
selected). An alarm upload and email will also be sent (if selected). If a new alarm is detected
within the De-bounce time, the timer will be reset for the alarm display, alarm output, tour,
PTZ, snapshot, channel recording and buzzer (no new alarm upload or email are sent).
Alarm out: If an alarm occurred, the system will enable a peripheral alarm device connected to
the selected outputs (default is 1).
Latch: When the ‘De-bounce time’ is ended, the alarm output relay you selected in ‘Alarm out’
will remain activated for this extra ‘latch’ period (from 1 to 300 seconds - default is 10). The
latch is still valid even if you manually disable the alarm event.
PTZ activation: Here you can set PTZ movement when an alarm occurs. See below.
Delay: Set here an extra timer for channel recording to remain active (from 10 to 300 seconds
- default is 10) after the ‘De-bounce time’ has elapsed.
Display Mon. A: Here you can set which camera views are shown on Monitor A when an alarm
occurs. The system supports one- or multi-window views.
Display Mon. B: Here you can set which camera views are shown on Monitor B when an alarm
occurs. The system supports one- or multi-window views.
Send email: An alert email is sent if an alarm is detected.
Show message: The system will pop up a message in the local host screen to alert you.
Buzzer: Select here to activate the buzzer when an alarm occurs.
After completing setup, click <Save> to save your settings and go back to the previous menu.
Note
In the Detect menu, the Copy function is only valid for the same event type, which means you
cannot copy a channel setup in video loss mode to camera masking mode.
PTZ Set
Setup the PTZ as follows for each camera associated with the input:
1. Click on the drop-down menu to set the activation operation for:
None (default)
Shot – this will swivel the channel camera to a preset PTZ position this is setup in
the Camera > Configuration > PTZ submenu
Tour – this will switch the channel views in a preset sequence
Pattern – this will swivel the camera in a pre-assigned pattern
2. Click on the next field to enter a pre-position number from 0 (default) to 255 to send the
camera to a specified pre-position.
3. Repeat these steps for each of the PTZ cameras that require a preset.
If required, access the Pan/Tilt/Zoom menu (Main menu > Setting > Pan/Tilt/Zoom) to setup
the video channel, baud rate, dome protocol, etc.
Video loss
The recorder can process input alarms from the recorder alarm inputs and from IP camera
alarm inputs.
See section Alarm > Motion detect for a description of applicable fields.
One extra field not described is:
Type: choose between Normal open (default) or Normal closed for the input alarm type.
Input alarm
The recorder can process input alarms from the recorder alarm inputs and from IP camera
alarm inputs.
See section Alarm > Motion detect for a description of applicable fields.
8.4.2
8.4.3
DIVAR 2000 / DIVAR 3000 / DIVAR
5000
Settings | en 45
Bosch Security Systems Operation Manual 2016.09 | v1.0 | AM18-Q0717
