Bosch DIVAR 3000 User Manual

Web Client Software
The Web Client software (loaded on a PC) gives full remote control of the DIVAR over the web.
Up to four remote users can access and control the unit. Remote live viewing, search,
playback, and system configuration are provided. Remote control functions include pan/tilt/
zoom control of cameras, and video archiving. An on-line status overview of the connected unit
is also provided.
To access a unit, a user must log on using the same User ID and Password used for local
access. The Web Client will follow the permissions of the user account, restricting the
functions available to each remote user; for example, the ability to archive video. See
Operating instructions for more details on User Levels.
The recommended PC requirements for running Web Client are:
– Operating platform: A PC running Windows XP, Windows Vista, or Windows 7.
– Processor: Intel Core Duo, 2.0 GHz or comparable
– RAM memory: 2048 MB
– Free hard disk space: 10 MB
– Graphics card: NVIDIA GeForce 8600 or higher
– Network interface: 10/100-BaseT
– Web Browser: The current product series supports Internet Explorer, Firefox, and Google
Chrome (QuickTime required; no playback supported).
Getting started
To use the Web Client, first connect your PC and the DIVAR via a TCP/IP network connection
and load a new Web Client version as follows:
1. In the DIVAR, go to the network setup (stored in Main menu > Setting > Network) and
check that the network settings are correct. You can also see here the IP address for the
DIVAR. Make a note of the IP address for the next step.
2. On your PC start the Windows Command prompt: click Start > type "cmd" in the search
field. Type "ping ***.***.***.***" (***= IP address) to check the connection. The return TTL
value should be less than 255.
3. Open an internet browser on your PC and input the IP address for the DIVAR in the
address column. For example, if the address is 10.10.3.16, then input http:// 10.10.3.16
in the IE address column. See following example.
4. The browser will ask to download and run the latest Web Client webplugin.exe (or
overwrite the previous version). Always check first with your system administrator that
you have sufficient rights to install the web client software on your PC (the web client
executables will be loaded into the directory Program Files (x86) \ webrec).
5. Follow the dialog boxes to correctly install the Web Client. Once installed, the screen will
refresh and show the login screen.
Note: The Web Client does not install ‘webrec’ on a PC again unless a new version is released
with new firmware.
11
11.1
DIVAR 2000 / DIVAR 3000 / DIVAR
5000
Web Client Software | en 77
Bosch Security Systems Operation Manual 2016.09 | v1.0 | AM18-Q0717

Bosch DIVAR 3000 Specifications

General

AC input voltage	100 - 240 V
AC input frequency	50 - 60 Hz
Power consumption (max)	20 W
Storage temperature (T-T)	0 - 93 °C
Operating temperature (T-T)	0 - 40 °C
Storage relative humidity (H-H)	0 - 95 %
Operating relative humidity (H-H)	-40 - 70 %
Sustainability certificates	RoHS
Certification	EMC, LVD, UL, cUL, CAN/CSA, BIS, RCM, ACMA EMC, CE, FCC
On/off switch	Yes
Product color	Black, Silver
Rack capacity	-
Bit rate	24000 Kbit/s
Display modes	Live view
Playback modes	Fast play, Forward, Frame by Frame, Reverse, Slow play
Input bandwidth	320 Mbit/s
Number of users	128 user(s)
Recording modes	Manual, Schedule, Stop
Output bandwidth	256 Mbit/s
Maximum resolution	3840 x 2160 pixels
Alarm input channels	16
Video input channels	16 channels
Alarm output channels	3
Supported resolutions	3840×2160, 1920×1080, 1280×1024, 1280×720, 1024×768, 970x576, 704x576, 352x576, 352x288, 176x144, 960x480, 704x480, 352x480, 352x240, 176x120
Video recording modes	720p, 1080p
Video formats supported	H.264, H.265, M-JPEG
RS-232 ports	1
Audio RCA inputs	4
Networking standards	IEEE 802.3
USB 2.0 ports quantity	USB 2.0 ports have a data transmission speed of 480 Mbps, and are backwards compatible with USB 1.1 ports. You can connect all kinds of peripheral devices to them.
Ethernet LAN data rates	10, 100, 1000 Mbit/s
Ethernet LAN (RJ-45) ports	2
Supported network protocols	HTTP, HTTPS, TCP/IP, IPv4/IPv6, UPnP, RTSP, UDP, SMTP, NTP, DHCP, DNS/DDNS, IP Filter, PPPoE, FTP
Copper ethernet cabling technology	10BASE-T, 100BASE-T, 1000BASE-T
Wi-Fi	No
HDD capacity	- GB
HDD interface	Serial ATA
Maximum storage capacity	6 TB
Mobile operating systems supported	Android, iOS

Weight and Dimensions

Depth	323 mm
Width	375 mm
Height	53 mm
Weight	4130 g
