Bosch DIVAR 3000 User Manual

In PTZ mode, use to control the tilt functions of the selected
camera
In text mode or when choosing a camera channel, input
number 3 or 9 (only on the DIVAR 2000/3000)
Left Right In menu mode, move around through menu items or values
In PTZ mode, use to control the pan function of the selected
camera
In playback, click to control playback bar
In text mode or when choosing a camera channel, input
number 6 or 7 (only on DIVAR 2000/3000)
ESC ESC Go to previous menu, or cancel current operation
In playback, click to restore real-time monitor mode
Enter Select a submenu or menu item, or confirm selections made in
menus
Go to default button
Go to Quick menu
Window switch Mult Click to switch between one-window and multiple-window (2,
4, 9, and 16)
Assistant Fn In one-window monitor mode, click to display assistant
function: PTZ control and image color
In motion detection setup, use the Fn and direction keys for
setup
In text mode, click to switch between numeral, English
character (small/capitalized), etc.
Press for 1.5 seconds to delete the previous character before
the cursor
Realize other special functions
Slow forward Multiple slow play speeds or normal playback
In text mode or when choosing a camera channel, input
number 5 (only on DIVAR 2000/3000)
Fast play Various fast speeds and normal playback
In text mode or when choosing a camera channel, input
number 4 (only on DIVAR 2000/3000)
Play previous In playback mode, playback the previous video
In text mode or when choosing a camera channel, input
number 7 (only on DIVAR 2000/3000)
Reverse/Pause In normal playback or pause mode, click to reverse playback
In reverse playback, click to pause playback
In text mode or when choosing a camera channel, input
number 1 (only on DIVAR AN 3000 )
52 en | Operation
DIVAR 2000 / DIVAR 3000 / DIVAR
5000
2016.09 | v1.0 | AM18-Q0717 Operation Manual Bosch Security Systems

Bosch DIVAR 3000 Specifications

General

AC input voltage	100 - 240 V
AC input frequency	50 - 60 Hz
Power consumption (max)	20 W
Storage temperature (T-T)	0 - 93 °C
Operating temperature (T-T)	0 - 40 °C
Storage relative humidity (H-H)	0 - 95 %
Operating relative humidity (H-H)	-40 - 70 %
Sustainability certificates	RoHS
Certification	EMC, LVD, UL, cUL, CAN/CSA, BIS, RCM, ACMA EMC, CE, FCC
On/off switch	Yes
Product color	Black, Silver
Rack capacity	-
Bit rate	24000 Kbit/s
Display modes	Live view
Playback modes	Fast play, Forward, Frame by Frame, Reverse, Slow play
Input bandwidth	320 Mbit/s
Number of users	128 user(s)
Recording modes	Manual, Schedule, Stop
Output bandwidth	256 Mbit/s
Maximum resolution	3840 x 2160 pixels
Alarm input channels	16
Video input channels	16 channels
Alarm output channels	3
Supported resolutions	3840×2160, 1920×1080, 1280×1024, 1280×720, 1024×768, 970x576, 704x576, 352x576, 352x288, 176x144, 960x480, 704x480, 352x480, 352x240, 176x120
Video recording modes	720p, 1080p
Video formats supported	H.264, H.265, M-JPEG
RS-232 ports	1
Audio RCA inputs	4
Networking standards	IEEE 802.3
USB 2.0 ports quantity	USB 2.0 ports have a data transmission speed of 480 Mbps, and are backwards compatible with USB 1.1 ports. You can connect all kinds of peripheral devices to them.
Ethernet LAN data rates	10, 100, 1000 Mbit/s
Ethernet LAN (RJ-45) ports	2
Supported network protocols	HTTP, HTTPS, TCP/IP, IPv4/IPv6, UPnP, RTSP, UDP, SMTP, NTP, DHCP, DNS/DDNS, IP Filter, PPPoE, FTP
Copper ethernet cabling technology	10BASE-T, 100BASE-T, 1000BASE-T
Wi-Fi	No
HDD capacity	- GB
HDD interface	Serial ATA
Maximum storage capacity	6 TB
Mobile operating systems supported	Android, iOS

Weight and Dimensions

Depth	323 mm
Width	375 mm
Height	53 mm
Weight	4130 g
