Figure 9.3: Remote control
See the following table for detailed information on each of the remote control buttons.
Button ID
Name Function
1 Power button Start up or shut down the device (may be password
protected)
2 Address Input a device number to be controlled
3 Forward Multiple fast-forward speeds or normal playback
4 Slow forward Multiple slow-play speeds or normal playback
5 Play next In playback mode, playback the next video
6 Play previous In playback mode, playback the previous video
7 Play/Pause In pause mode, click for normal playback
In normal playback, click to pause playback
In real-time monitor mode, click to enter video search
menu
8 Reverse/pause In reverse playback pause mode, click for normal
playback
In reverse playback mode, click to pause playback
54 en | Operation
DIVAR 2000 / DIVAR 3000 / DIVAR
5000
2016.09 | v1.0 | AM18-Q0717 Operation Manual Bosch Security Systems
