4.2 Parameterizing the drive
 Start the DSS monitor.
 Load the template file (page 4–2) into the monitor using ”Import”.
For every specified parameter, the related value is read from the connected
drive and shown as follows:
 Adjust the individual parameter values to your requirements in the course of
the parameterization procedure (for mode of functioning of the DSS monitor,
cf. page 3–3).
The following sections are not based on the parameter numbers, but rather
on the higher-level function.
 Please note that the current drive phase may have to be changed prior
to a parameter change (cf. page 3–8).
 After having parameterized a function, test it for the proper drive behavior
and signal sequence.
If this is the case, perform the ”Save main memory” command (cf. section
3.5.2).
