Diagnoses
6–1
1070 066 037-101 (00.02) GB
6 Diagnoses
6.1 Drive configuration
You will be shown static information on:
software version (firmware version)
module and motor type
current DSS operation mode
application
interface type and version
DSS errors
Diagnostics class 1 errors
Select the menu sequence:
DIAGNOSES MODULE CONFIGURATION, or
click on the
command button in the DSS basic image and then
select ”Module configuration”.
Do not perform any operations (mouse click, keyboard entry, etc.) before the
module configuration display appears. The DSS will only read the necessary
information from the drive when the module configuration display is called
up, this process may take a few seconds.
The Logbook area is not used for drives with a CANrho interface.
