Bosch SOLUTION 6000 Installation Guide

Solution 6000  Installation Manual  Wiring Diagrams
3-5
Bosch Security Systems 07-14 BLCC610I
N12138 N12138
VISION-GRAPhIC
Powered by
Security & Access Controller
DIGIFLEX
P/Nº: MFG:
CC720 01-Mar-11
VER:
2.00
N12138
N12138
P/Nº: MFG:
CC610 12 Oct 2013
SOLUTION 6000 Intrusion Control Panel
VER: 2.00
RoHS

16-18 VAC
24VA
12VDC 7.2Ah Sealed
Lead Acid Battery
Panasonic LC-P127R2P
or Equivalent
Accessory
12 VDC Supply
(750mA Fused)
LAN Devices
Connection
Terminals
(750mA Fused)
Output 1, 2, 3 and 4
Connection Terminals
500mA
RF Receiver
/ Keyswitch
Input
Zone Input
Terminals
Telephone Line
Connection
Terminals
Telephone Line
Connection Socket
(RJ12 6P4C)
Panel Cabinet
Tamper Circuit
Connection
Terminals
Battery
Charging
Globe
Voice Module
Connection
Socket
(Optional)
4-Pin Socket
to LAN For
Service Keypad
Default and
Direct Connect
Switch
10-Pin Serial
Connection
Socket For Direct
Link / Flash
Programming
etc.
Relay COM
Terminal
Programming
Shunt
Expansion Port
TCP/IP, GSM
Module
Connection
RS485 LAN
Termination
Shunt
Earth Connection
Spade For Surge
Protection
Output Devices
12VDC Supply
(2.5A Fused)
The maximum
continuous
combined
current draw
from the +12V,
LAN + and
C+ terminals
must not
exceed 1 Amp
Ouput 5
Relay Output
24V D.C. 2Amp
Refer to
Documentation
For Dialer &
Status LED’s
X
G
SP
Figure 24: Terminal Descriptions

Bosch SOLUTION 6000 Specifications

General

Partitions	8
System Type	Hybrid wired/wireless security system
Keypads	Up to 16
Communication	PSTN, optional IP module, optional GSM/GPRS module
Arming Modes	Stay, Away
Power Supply	16.5VAC
Backup Battery	12V 7Ah
Operating Temperature	0°C to +50°C
