Bosch SOLUTION 6000 Installation Guide

Solution 6000  Installation Manual  Wiring Diagrams
3-6
Bosch Security Systems 07/14 BLCC610I
X
G
SP
N12138
N12138
P/Nº: MFG:
CC610 12 Oct 2013
SOLUTION 6000 Intrusion Control Panel
VER: 2.00
RoHS

Premises
Telephone
Incoming Street
Telephone Line
+
-
GREEN
YELLOW
YELLOW
16-18V AC
24 VA
ZONE 2
ZONE 4
ZONE 1
ZONE 3
N/C
N/C
N/C
N/C
N/C
ZONE 6
ZONE 8
ZONE 5
ZONE 7
N/C
N/C
N/C
N/C
LAN B
LAN -
LAN A
LAN +
Keypad /
LAN Expansion
Device
Horn
Speaker
Strobe Light
+
-
12V DC
7.2AH Sealed
Lead Acid Battery
Accessories
(e.g. PIR Detectors)
Siren Tamper Switch
Connect To
Cabinet Tamper
To Zone Terminals
+
NC
COM
-
-
+
RJ12 6P4C - RJ12 6P4C
Phone Lead
Connect To
Telephone Line
Mode 3
Smoke
Detector
RF
Receiver
Connect
To
Accessory
Power
GND
+12V
RF DATA
Earth Connection
Spade For Surge Protection
Panasonic
LC-P127R2P
or Equivalent
Ouput 5
Relay Output
24V D.C. 2Amp
Relay COM
Terminal
Programming
Shunt
The maximum
continuous
combined
current draw
from the +12V,
LAN + and
C+ terminals
must not
exceed 1 Amp
Piezo Siren
+
-
3K3
Fit the supplied
3K3 resistor
across the piezo
siren so the panel
can monitor the
connection.

Figure 25: Wiring Diagram

Bosch SOLUTION 6000 Specifications

General

Partitions	8
System Type	Hybrid wired/wireless security system
Keypads	Up to 16
Communication	PSTN, optional IP module, optional GSM/GPRS module
Arming Modes	Stay, Away
Power Supply	16.5VAC
Backup Battery	12V 7Ah
Operating Temperature	0°C to +50°C
