i5100 Conguration Manual
6.1.4 Tearing-off
 Start menu.
 Select Setup > Tearing-off.
Parameter Meaning Default
Tear-off mode Positioning the label medium for tearing off at the tear-off plate.
On: Additional advancement of the label medium which positions the
label gap after the last printed label at the dispense plate.
Off: Label advance stops once the last label has fully passed the print
line.
On
Tear-off position Shiftingofthetear-offpositioninthedirectionofpaperow.With
positive values, the label strip is transported farther out of the printer.
0.0 mm
Table 8 Parameters of the Setup > Tearing-off menu
6.1.5 Cutting

Ifcutterisnotinstalled,accessonlywithservicekeyinserted.
 Start menu.
 Select Setup > Cutting.
Parameter Meaning Default
Cut position Offset of the cut position relative to the rear label edge.
The setting can also be adjusted by the software.
Thesettingsofconguration and software are added together.
0.0 mm
Table 9 Parameters of the Setup > Cutting menu
6.1.6 Peeling-off

Ifpeel-offmoduleisnotinstalled,accessonlywithservicekeyinserted.
 Start menu.
 Select Setup > Peeling-off.
Parameter Meaning Default
Peel-off position Shift the position of the dispensed label relative to the dispensing edge.
The setting can also be adjusted by the software.
Thesettingsofconguration and software are added together.
0.0 mm
Backfeed delay Delay time between removing the label from the peel position and the
backfeed of the label.
250 ms
Table 10 Parameters of the Setup > Peeling-off menu
6 Conguration
