8 Diagnostic Functions
8.3 LabelProle
The Label prole function carries out a longer label advance. It saves the values measured by the label sensor here and
then prints them out in a diagram.
The printout is used to check label detection in conjunction with the optical properties of the label medium.
TheprintoutoccursusingtheheatlevelandprintspeedspeciedintheSetup > Printing menu.
i
Notice!
Theprintoutoccurswithouttakingthelabelgapsintoconsideration.Thisiswhyendlessmediaaremost
suitableforthispurpose.
 Select the label sensor to be tested in the Setup > Labels menu  page 19.
 Load the label medium to be tested into the printer.
 Start menu.
 Select Diagnostics > Label prole.
Theprinterperformsalongerlabeladvance.Thelabelsensormeasuresthetransparency/reectioncapacityofthe
label material here. The message Insert appears in the display once the advance is complete.
 Insert printable medium (labels, endless paper) which extends across the entire printing width.
 If the printout is to occur using thermal transfer printing, insert transfer ribbon with the maximum width.
 Start the diagram printout with Continue.
The printout can be canceled with .
Label prole
Tue Feb 13 13:51:19 2018
Brady i5100-300
Firmware V5.14 (Feb 09, 2018) - #164162032326
Gap Sensor - 50 mm/s - Brightness 109
71.74mm - σ² 0.014mm²
1
2
3
4
Figure 20 Labelprole
No. Information
1 Date and time of the printout
Device type
Versionandcreationdateofthermware
Serial number of the PCB CPU
Firmware version and serial number of the label sensor
2 Coordinateinthedirectionofpaperowatwhichthelabelstartwasdetected
3 Printspeed,methodoflabeldetection(Gapsensor/Bottom-reectsensor)
Brightness of the sensor LED during the measurement
4 Average value and variation of label distances
Table 25 Information in Label prole
