i5100 Conguration Manual
8 Diagnostic Functions
8.7 Save System Log

Accessonlywithexternalstoragedevice!
The function Save system logallowstostoreseveralsystemlespackedtoa.zipletoanexternalstoragedevice
(SD card, USB memory module) installed on the printer.
 Insert SD card or USB memory module.
 Start menu.
 Select Diagnostics > Save system log.
 Select the external storage device.
 Enteralename.
Thepredenednameiscomposedoftheidentier"sys",date,clocktimeandthesufx".png",butmayalsobe
altered.
 Conrmtheselectionwith . The display shows the several steps of saving.
Figure 24 System log saving
 Conrmthecompletionofsavingwith .The.ziplewillbestoredintherootofthestoragedevice.
