i5100 Conguration Manual
12 Storage Devices
Label descriptions, graphics, fonts, and database information can be saved for the long-term on memory media.
i
Notice!
 Alwayscreateabackupcopyofexternaldevicesincaseofamalfunction.
12.1 Suitable Storage Devices
External Devices
• USBashdriveatUSBmasterinterface.
• SD cards
Internal Device
• approx.50MBashmemoryinsidetheprinter(InternalFlashFileSystemIFFS)
12.2 Installation

For external storage devices only!
 SlideSDcardcontact-siderstintothematchingslotuntilitlatches.
To unlatch SD card press it shortly into the slot and remove it.
or
 ConnectUSBashdrivetoanUSBmasterinterface.
!
Attention!
Risk of data loss !
 Donotremovethestoragedevicewhileitisbeingaccessed.
12.3 Directory Structure
On storage devices connected to the printer, the following directory structure is automatically generated when uploading
les:
Folder name Contents
fonts Fontles
images Graphicles
labels Labeldescriptionles
misc Firmware,PPP,SetupandTMPles
Table 29 Directory structure
