7 Test Functions
7.1 Overview
The Test menu contains test functions providing information on:
• themostimportantcongurationparameters
• the fonts available in the printer
• important hardware components and connected peripheral devices
• the print image quality and state of the thermal printhead
• available Wi-Fi networks.
7.2 Status Print
The Status printfunctionprintsatestimagecontaininginformationonthecongurationandstatusoftheprinter.The
printoutoccursusingtheheatlevelandprintspeedspeciedintheSetup > Printing menu.
i
Notice!
Theprintoutoccurswithouttakingthelabelgapsintoconsideration.Thisiswhyendlessmediaaremost
suitableforthispurpose.
 Insert printable medium (labels, endless paper) which extends across the entire printing width.
 If the printout is to occur using thermal transfer printing, insert transfer ribbon with the maximum width.
 Start menu.
 Select Test > Status print.
The printout can be canceled with .
Status print
Tue Feb 13 10:28:21 2018
Brady i5100-300
Firmware V5.14 (Feb 09, 2017) - #164162032326
Printing
Heat level 0
Print speed 75 mm/s
Print position X 0.0 mm
Print position Y 0.0 mm
Backfeed smart
Backfeed position 1.0 mm
Print on demand Off
Reprint Re-render
Length scale 0.0 %
Slippage correction Off
Labels
Label sensor Gap
Extrapolate labels Off
Ribbon
Transfer print On
Warn level ribbon 32 mm
Pause on warning Off
Monitor ink side Off
Tearing-off
Tear-off mode On
Tear-off position 0.0 mm
Cutting
Cut position 0.0 mm
Peeling-off
Peel-off position 0.0 mm
Backfeed delay 250 ms
Interfaces
Ethernet
Hostname brady-05bb9d
DHCP Off
IP address 192.168.9.13
Netmask 255.255.255.0
Gateway Off
DNS server 0.0.0.0
Wi-Fi
Wi-Fi On
Access Point guest
DHCP Off
IP address 172.20.200.93
Netmask 255.255.255.0
Gateway Off
DNS server 0.0.0.0
Network services
FTP On
LPD On
RawIP On
RawIP port 9100
RawIP timeout Default
Website On
Web service On
SNMP On
SNMP community public
VNC server On
Zeroconf On
RS-232
Baud rate 115200
Handshake RTS/CTS
Errors
Error-Reprint On
Syntax error On
Barcode error On
Network error On
Region
Language English
Country USA
Keyboard Automatic
Time
Date 02/13/2018
Time 10:28:21 AM
Time zone UTC-6 (Central Am.,Chicago)
Daylight saving USA
Time synchronization NTP
Time server
Display
Brightness 8
Time powersave 5 min
Interpreter
Character set UTF-8
USB JScript
RS-232 JScript
FTP JScript
LPD JScript
RawIP JScript
Bluetooth JScript
ZPL
Print width 100.0 mm
Label length 150.0 mm
Storage
Default storage SD Card
Security
PIN protection On
Extras
Cleaning interval 1000 m
Service
Printhead zero pos. X 0.0 mm
Printhead zero pos. Y 0.0 mm
Printer Info
Operative time
Total 32h 53min
Service -
Number of labels
Total 2928
Service -
Thermal transfer
Total 32.517 m
Service 20.154 m
Thermal direct
Total 212.275 m
Service -
Temperature 25.9 °C
Heat voltage 24.1 V
Heat level
< 0 22.077 m
0-7 190.198 m
8-14 0.000 m
> 14 0.000 m
Label sensor
Brightness 2-4 / 22-139
Figure 14 Status print
Parameters marked italic are only printed when the printer is equipped with the respective optional assembly
or when the service key is inserted
