i5100 Conguration Manual
7 Test Functions
7.6 Wi-FiStatus

AccessonlywhenaWi-FistickisinstalledandWi-Fiisactivated!
NotintheWi-Fioperationmode"Hotspot".
The Wi-Fi status function prints out a list with the most important parameters of the accessible Wireless Access Points. The
printoutoccursusingtheheatlevelandprintspeedspeciedintheSetup > Printing menu.
i
Notice!
Theprintoutoccurswithouttakingthelabelgapsintoconsideration.Thisiswhyendlessmediaaremost
suitableforthispurpose.
 Insert printable medium (labels, endless paper) which extends across the entire printing width.
 If the printout is to occur using thermal transfer printing, insert transfer ribbon with the maximum width.
 Start menu.
 Select Test > Wi-Fi status.
The printout can be canceled with .
Wi-Fi status
Tue Feb 13 12:47:29 2018
Brady i5100-300
Firmware V5.14 (Feb 09, 2018) - #164162032326
Channel Name/BSS ID Signal level Security
1 default
●●●●●
WPA2-PSK
00:24:b2:36:98:60
1 brady-dev
●●●●●
WPA2-PSK
00:24:b2:36:98:61
1 brady-guest
●●●●●
WPA2-PSK
00:24:b2:36:98:62
11 default
●○○○○
WPA2-PSK
00:24:b2:36:98:60
11 brady-dev
●○○○○
WPA2-PSK
00:24:b2:36:98:61
11 brady-guest
○○○○○
WPA2-PSK
00:24:b2:36:98:62
Figure 18 Wi-Fi status
The parameters have the following meaning :
Column Meaning
Channel Channel; frequency range of the Access Point
Name/BSS ID Name of the wireless LAN
MAC address of the Access Points
Signal level Scale of the Wi-Fi signal strength
Security Type of data encryption
Table 23 Parameters of the WiFi status
