i5100 Conguration Manual
2 Connecting Label Printer to Computer
2.3 Connecting Label Printer via EthernetInterface
To connect the label printer to a network jack, a patch cable with an RJ45 plug for 10 Base T or 100 Base T is required.
!
Attention!
 Useashieldedcabletoconnecttheprintertothenetwork.
 Connect computer and label printer with a suitable cable.
 Make the settings for operation of the Ethernet interface  6.1.7 on page 21.
 Set up print service if necessary  2.1 on page 6.
 Adjust Windows printer setting  2.2 on page 6.
!
Attention!
 Donotchangethesettingsofthe"IP"and"Gateway"ontheprinterwebinterface,asotherwisethe
connectiontotheprintermaybelost.
2.4 SettingUpaWi-FiConnection
2.4.1 ConnectingPrintertoNetwork

AccessonlywithserviceWi-Fistickinstalled.
i
Note!
Thatmodeallowstouseanexistingwirelessnetworkforcontrollingandconguringtheprinterandforsending
printjobstotheprinter.
 Start menu.
 Select Setup > Interfaces > Wi-Fi.
 Activate Wi-Fi  page 22.
 Select Operation mode > Connect to network.
 Select Access-Point.
The search for access-points will be started.
The display shows the available access-points including the hidden access-points.
 Selectanaccesspointanconrmwith .
 For hidden access-points enter the SSID.
 Setup DHCP or IP and Mask and if necessary Gateway.
 If the network is protected a prompt to enter the passkey appears in the printer display. Enter the passkey and select
.
 Set up print service if necessary  2.1 on page 6.
 Adjust Windows printer setting  2.2 on page 6.
!
Attention!
 Donotchangethesettingsofthe"IP"and"Gateway"ontheprinterwebinterface,asotherwisethe
connectiontotheprintermaybelost.
