i5100 Conguration Manual
14 External Keyboard
An external keyboard or a compatible input device (e.g. barcode scanner) can be connected directly to the printer. Using
an external keyboard facilitates the entry of variable data while processing print jobs and printing from storage devices.
Input prompts and the data received from the keyboard are shown in the display.
14.1 Connecting External Keyboard
Any HID compatible USB keyboard can be connected to the printer.
 Insert connection cable of the keyboard into a USB master interface of the printer.
14.2 Keyboard Assignment
 If necessary set the parameter Setup > Region > Keyboard matching to the used keyboard.
i
Notice!
 IftheparameterKeyboard is set to Automatic,thekeyboardassignmentwillbedenedbythesettingofthe
parameter Country.
The following Country settings have special keyboard assignment :
Country Keyboard
China USA
South Africa USA
Taiwan USA
Mexico Latin America
Egypt Arabic
Table 30 Special assignments Country - Keyboard
For the following Keyboard settings can be switched between two assignments by pressing the CTRL key and the SHIFT
key:
Keyboard First assignment Second assignment
Bulgaria Latin Cyrillic
Greece Latin Greek
Iran Latin Persian
Macedonia Latin Cyrillic
Russia Latin Cyrillic
Thailand Latin Thai
Arabic Latin Arabic
Table 31 Keyboard settings with double assignment
