i5100 Conguration Manual
6 Conguration
6.1.2 Labels
 Start menu.
 Select Setup > Labels.
Parameter Meaning Default
Label sensor Method for detecting the starting end of the label.
Gap Sensor: Detection using changes in the transparency between the
label and label gap.
Bottom-Reect:Detectionusingreexmarksonthebottomofthemedium.
Continuous media: Checking the existence of media only.
Gap sensor
Extrapolate labels The positions of the labels which are between the label sensor and the
printheadarecalculatedfromtherstlabelrecognizedbythesensor
and the programmed label distance. That way those labels can be
printed although the printhead previously was open.
Off
Table 6 Parameters of the Setup > Labels menu
6.1.3 Ribbon
 Start menu.
 Select Setup > Ribbon.
Parameter Meaning Default
Transfer print On: Sensor for monitoring the transfer ribbon is activated.
Off: Sensor for monitoring the transfer ribbon is not activated.
The setting can be overwritten for each print job via software. The basic
setting is not changed by this.
On
Warn level ribbon Threshold diameter (32–74 mm) of the ribbon supply roll, if the value is
undershot the "ribbon low" message will be activated
Off
Pause on warning The print job will be interrupted when the "ribbon low" message appears Off
Monitor ink side Setting of the ribbon unwinding direction
The print job will be interrupted when the wrong ribbon winding direction
has been detected. The error message "Ribbon ink side" appears.
Off
Table 7 Parameters of the Setup > Ribbon menu
