i5100 Conguration Manual
8 Diagnostic Functions
The Diagnostics menu contains several functions for troubleshooting
8.1 Printhead
The function Printhead provides an overview of important status information concerning the printhead on the display of the
printer.
 Start menu.
 Select Diagnostics > Printhead.
 Return with Close.
The following parameters are displayed:
Line Meaning Example
1 Serial number of the printhead Serial no.
72-0109
2 Part number of the printhead Part no.
5977444
3 Firmware revision of the printhead Firmware
2.1.0
4 Temperature of the printhead Temperature
26.1 °C
5 Resolution of the printhead Resolution
12 DPMM (dots/millimeter)
6 Print width / Number of dots Width/no. of dots
106mm/1248
7 Operative time/Number of printed labels
with the current printhead
Hours/no. of labels
34h/2935
8 Previously printed paper lengths with thermal direct printing / thermal
transfer printing
Thermal/Transfer
0.00m/214.26m
9 Previously printed paper length with heat level < 0 Heat level <0
22.08m
10 Previously printed paper length with heat level 0 - 7 Heat level 0-7
192.18m
11 Previously printed paper length with heat level 8 - 14 Heat level 8-14
0.00m
12 Previously printed paper length with heat level > 14 Heat level >14
0.00m
13 Resistance of the printhead Resistance
1078Ω
14 Description of the printhead Description
4"/300dpi/Kyocera
Table 24 Printhead display
