INFUSOMAT® SPACE OVERVIEW
6
Attaching Pole Clamp to IV Pole
Position the opening of the Pole Clamp
on pole and turn black knob clockwise
until pole clamp is secured to IV pole.
Turn black knob counter clockwise to
release from IV pole.
Attaching Pump to Pole Clamp
Line up slots on top sides of pump with
grooves of Pole Clamp and slide pump
into Pole Clamp until locking mecha-
nism clicks.
Space Pole Clamp (speed clamp)
(model 8713131)
The pump is now securely attached to the
pole clamp.
• Do not position the pump unit over
the patient.
