Brocade FastIron X Series Chassis Hardware Installation Guide 19
53-1001723-02
Hardware features
1
Table 6 lists the management modules for the FSX 800 and FSX 1600.
NOTE
512 MB SDRAM enables support for large routing tables (1,000,000 BGP routes) with the full Layer
3 code.
NOTE
The IPv6 management modules ending with -PREM provide additional support for full Layer 3 IPv4
routing protocols. The IPv6 management modules ending with -PREM6 provide additional support
for full Layer 3 IPv4 and IPv6 routing protocols.
The FSX 800 and FSX 1600 management modules perform the following tasks:
Control the hardware components
Control the separate switch fabric modules
Run the networking protocols
Provide the real time operating system
FSX 800 management modules are located in slots 9 and 10, just above the switch module slots
(refer to Figure 4).
FSX 1600 management modules are located in slots 9 and 10 along the center of the chassis
(refer to Figure 6).
TABLE 6 FSX 800 and FSX 1600 management modules
Part Number Description Microprocessor
Speed (MHz)
MB SDRAM
IPv4 Management Modules
SX-FIZMR no ports 667 512
SX-FIZMR-PREM
SX-FI2XGMR4 two 10-GbE ports 667 512
SX-FI2XGMR4-PREM
SX-FI8GMR4 eight GbE ports (four
copper and four fiber
667 512
SX-FI8GMR4-PREM
IPv6 Management Modules
SX-FIZMR-6-PREM no ports 667 512
SX-FIZMR-6-PREM6
SX-FI2XGMR6 two 10-GbE ports 667 512
SX-FI2XGMR6-PREM
SX-FI2XGMR6-PREM6
SX-FI8GMR6 eight GbE ports (four
copper and four fiber)
667 512
SX-FI8GMR6-PREM
SX-FI8GMR6-PREM6
