mRJ21 procedures
3
Cable cinch with two mRJ21 cables
To secure two mRJ21 cables, place the Velcro strap through slot one and use the front and rear left
recesses as shown in Figure 94.
FIGURE 94 Two mRJ21 cables
T
Cable cinch with three mRJ21 cables
Three mRJ21 cables may be secured as shown in Figure 95.
FIGURE 95 Three mRJ21 cables
