II.4 Navigation
  TheDV2TViscometerusesatouchscreendisplay.Navigationoftheinstrumentfeaturesisdone
usingavarietyofDataFields,Arrows,CommandKeysandNavigationIcons.Theoperating
systemhasbeendesignedforintuitiveoperationandemployscolortoassisttheuserinidentifying
options.
DataFieldsrequirethattheusertouchthescreen
toinitiatethedataentry/selectionprocess.These
eldsare normallyoutlined in black.They may
also include a blue arrow.
BlueArrowsindicatethatoptionsexistforaData
Field.Theusermayberequiredtopressanywhere
intheDataFieldortheymayhavetopresstheBlue
Arrowspecically.
CommandKeysarebuttonswhichdirecttheDV2T
toperformaspecicactionsuchasSAVEadataset
orSTOPaprogram.CommandKeysarepresented
inavarietyofcolors.Thesekeysarenormallyfound
atthebottomofthescreen.
NavigationIconsarenormallyfoundintheTitleBar
totheleftandright.Thesebuttonswilltakeyouto
specicareasoftheoperatingsystem.
NavigationIconsareshownbelow.
Home Menu
Perform data entry from a scroll
list
Log In (will only be available if
theadministratorhasactivateduser
login)
Sortlesaccordingtocreatedate
Settings Menu
Sortlesaccordingtoalphabet
Service Menu (only available for
authorized Brookfield service
centers)
Choosefromadditionaloptions
LockOut(duringatest)
Back(returntopreviousscreen)
RemoveLock(duringatest)
Up (return to previous level in
thelestructure)
Perform data entry using a number
pad

Brookfield DV2T Specifications

General

Type	Viscometer
Model	DV2T
Repeatability	±0.2%
Data Output	USB, RS-232
Accuracy	±1.0% of range
Temperature Range	Optional temperature probe
Power Supply	100-240V, 50/60Hz
Display	5-inch Color Touch Screen
Viscosity Range	1-2, 000, 000 cP
