Brookeld Engineering Labs., Inc. Page 85 Manual No. M13-167
Appendix I - DVE-50A Probe Clip
ProbeClipDVE-50AissuppliedwithallmodelDV2TViscometers,DV-IIIRheometers,and
DigitalTemperatureIndicators.ItisusedtoattachtheRTDtemperatureprobetotheLVGuard
Leg(PartNo.B-20Y)or600mLlowformGrifnbeaker.FigureI-1isaviewoftheProbeClip,
showingtheholeintowhichtheRTDprobeisinserted,andtheslotwhichtsontotheLVguard
leg.WheninsertingtheRTDprobeintotheProbeClip,theupperpartoftheClipiscompressed
bysqueezingthepointsshowninFigureI-1.
Note: AllViscometer/Rheometermodels—exceptLV—usetheProbe
ClipasshowninFigureI-3.
RTD Probe
Hole
Squeeze Here when
installing RTD
Temperature probe
Figure I-1
FigureI-2shows the ProbeClip(withRTDtemperature probe installed)mountedonthe LV
guard leg.
FigureI-3showstheProbeClipmountedina600mLlowformGrifnbeaker.Thismounting
maybeusedwithLV,RV,HAandHBseriesinstruments.
Caution: Temperature probe must not contact the spindle during
measurement.
Note: TheRTDprobemustbeparalleltothebeakerwallsoasnotto
interferewiththeviscositymeasurement.
Figure I-2
Figure I-3
Brookfield 600 mL Low Form
Griffin Beaker
DVE–50
Probe Clip
RTD Temperature Probe
LV Guard Leg
Assembly B-20KY
Probe Clip
DVE-50
RTD Temperatur e
Probe
