Brookfield DV2T User Manual

Brookeld Engineering Labs., Inc. Page 8 Manual No. M13-167
I.2 Utilities
InputVoltage: 115VACor230VAC
InputFrequency: 50/60Hz
PowerConsumption: 150VA
Power Cord Color Code:
United States Outside United States
Hot(live) Black Brown
Neutral White Blue
Ground(earth) Green Green/Yellow
Mainsupplyvoltageuctuationsarenottoexceed±10%ofthenominalsupply
voltage.
 I.3 Specications
Speeds: 0.1 - 200 RPM
Weight: GrossWeight 23 lbs. 10.5kg.
 NetWeight 20 lbs. 9kg.
 CartonVolume 1.65 cu.ft. 0.05m
3
 CartonDimensions22in.(56cm)Wx11in.(28cm)Lx22in.(56cm)H
Temperature Sensing Range: -100˚Cto300˚C(-148˚Fto572˚F)
USB A Port for use with an attached PC.
USB B Port (x3) for use with a USB Flash Drive.
Viscosity Accuracy: ±1.0%offullscalerange
 Theuseofaccessoryitemswillhaveaneffectonthe 
measurement accuracy. See Appendix B.
Viscosity Repeatability: ±0.2%ofFullScaleRange
Temperature Accuracy: ±1°C|-100°Cto+149°C
 ±2°C|+150°Cto+300°C
Operating Environment: 0°Cto40°Ctemperaturerange(32°Fto104°F)
 20%-80%R.H.:non-condensingatmosphere
Ball Bearing Option:
Ifyouorderedtheballbearingsuspensionsystemwithyournewinstrumentpleasenote
thefollowing:
1) TheballbearingsuspensioninyourBrookeldinstrumentisnotedontheserialtagon
thebackoftheheadbytheletter“B”inthepartnumber(theninthdigit;forexample:
XDV2THBTB00U00).
2) Whenattachinganddetachingthespindle,itisnotnecessarytoliftthecouplingwhere
thespindleconnectstotheinstrument.
3) TheOscillationCheckexplainedinSectionIV.1:DeviceSetup,doesnotpertainto
thisinstrument.

Brookfield DV2T Specifications

General

Type	Viscometer
Model	DV2T
Repeatability	±0.2%
Data Output	USB, RS-232
Accuracy	±1.0% of range
Temperature Range	Optional temperature probe
Power Supply	100-240V, 50/60Hz
Display	5-inch Color Touch Screen
Viscosity Range	1-2, 000, 000 cP
