Brookeld Engineering Labs., Inc. Page 39 Manual No. M13-167

IV. SETTINGS

TheSettingsmenuprovidesaccesstothemanycontrolsandfeaturesoftheDV2TViscometer.This

menucanbeaccessedthroughtheSettingsNavigationIcon whichisoftenpresentintheTitleBar.

FigureIV-1showstheSettingsMenuwhichisdividedinto:DeviceSetup,UserSettings,GlobalSettings,

andAdminFunctions.GlobalSettingsincludeitemsthataffectthecompleterangeoffeatureswithin

theDV2T.AdminFunctionsincludeitemsrelatedtoadministratorlevelcontrols.

Figure IV-1

IV.1 Device Setup

TheDeviceSetupmenuincludessettingsrelatedtothemechanicalsystemsandconnectionsofthe

DV2T.Sixsettingsareavailableincluding:

Temperature - Createoffsetstobeusedwithspecictemperatureprobes.

Printer Setup - DenetheprintformattobeusedwiththeDymo450Printer.

AutoZero - ForcetheDV2TtoperformanAutoZeroasisdoneatstartup.

OscillationCheck - EvaluatetheperformanceoftheDV2Tlowerbearings.

TechnicalSupportInfo - Informationthatmay be requestedbyBrookeldTechnical

Supportstafftoassistwithtroubleshooting.

About - PresentbasicinformationabouttheDV2Tasisdoneatstartup.

Temperature: TheTemperaturesettingallowstheusertocreateupto10temperatureoffsetvalues

forconnectedtemperatureprobes.Brookeldoffersseveraltypesoftemperature

probesforuse with theDV2Tincluding:DVP-94Y immersionprobe(supplied

withtheDV2T),CPA-44PYZembeddedprobe(optionalwithCone/PlateDV2T

Viscometers), and SC4-13RP embedded probe (optional with Small Sample

Adapter).Anyoftheseprobescanbecalibratedlocallyagainstastandardreference

thermometertodetermineanoffset(howfarfromtheactualtemperaturedoesthe

proberead).ThisoffsetcanbeenteredintotheDV2TViscometerandidentied

withanamedenedbytheuser.
