Brookeld Engineering Labs., Inc. Page 86 Manual No. M13-167
Appendix J - Fault Diagnosis and Troubleshooting
ListedaresomeofthemorecommonproblemsthatyoumayencounterwhileusingyourViscometer.
Spindle Does Not Rotate
Makesuretheviscometerispluggedin.
Checkthevoltageratingonyourviscometer(115,220V);itmustmatchthewallvoltage.
MakesurethemotorisONandthedesiredrpmisselected.
Spindle Wobbles When Rotating or Looks Bent
Makesurethespindleistightenedsecurelytotheviscometercoupling.
Checkthestraightnessofallotherspindles;replaceifbent.
Inspectviscometercouplingandspindlecouplingmatingareasandthreadsfordirt;cleanthreads
onspindlecouplingwitha3/56left-handtap.
Inspectthreadsforwear;ifthethreadsareworn,theunitneedsservice(seeAppendixM).Check
toseeifspindlesrotateeccentricallyorwobble.Thereisanallowablerunoutof1/32-inchin
eachdirection(1/16-inchtotal)whenmeasuredfromthebottomofthespindlerotatinginair.
Checktoseeiftheviscometercouplingappearsbent;ifso,theunitisinneedofservice(see
AppendixM:WarrantyRepairandService).
Inaccurate Readings
Verifyspindle,speedandmodelselection.
VerifyspindleselectioniscorrectonDV2T.
If%readingsareunder-range(lessthan10%),thedisplaywillash;changespindle and/or
speed.
“EEEE”onthedigitaldisplaymeanstheunitisover-range(greaterthan100%);reducespeed
and/orchangespindle.
Verifytestparameters:temperature,container,volume,method.Referto:
• “MoreSolutionstoStickyProblems”,SectionIII
• “DV2TViscometerOperatingInstructions”,AppendixC:VariablesinViscosityMeasurements
Performacalibrationcheck;followtheinstructionsinAppendixE.
Verifytolerancesarecalculatedcorrectly.
Verifythecalibrationcheckprocedureswerefollowedexactly.
Iftheunitisfoundtobeoutoftolerance,theunitmaybeinneedofservice.SeeAppendixM
fordetailsonWarrantyRepairandService.
