Brookeld Engineering Labs., Inc. Page 21 Manual No. M13-167
Measurementdatashouldnotbecollectedwhenthe%Torquereadingisoutofrange.Theoutof
rangeconditioncanberesolvedbyeitherchangingthespeed(reducespeedwhenreadingisoutof
range:high)orchangingthespindle(increasethespindlesizewhenthereadingisoutofrange:low).
TIP: Whencomparingdata,thetestmethodiscritical.Besurethatyouknowtheproperspindle
andspeedrequiredforthetestmethod.Ifreadingsareoutofrange,thisconditionshould
bereportedasthetestresult.
II.8 Printing
TheDV2TViscometercancommunicatetoaDymoLabelWriter450Turbolabelprinter.This
printercanbepurchasedfromBrookeld(PartNo.GV-1046).Thecommunicationtotheprinteris
byUSB(cableprovidedwiththeprinter).WhentheprinterisconnectedtotheDV2T,theprinter
iconwillbevisibleinthestatusbar.
TheDV2TViscometercanconguretheprintoutforseveralformatsofpaper/labels.These
variouspaper/labelstocksareavailablefromBrookeld.
1. GV-1049-10SHIPPINGLABEL2.31X4IN.300P/ROLL(PKGof10)
2. GV-1048-10ADDRESSLABEL1.13X3.5IN.350P/ROLL(PKGof10)
3. GV-1047-10CONTINUOUSPAPER2.25IN.WD.X300FT.LG(PKGof10)
Figure II-8

Brookfield DV2T Specifications

General

Type	Viscometer
Model	DV2T
Repeatability	±0.2%
Data Output	USB, RS-232
Accuracy	±1.0% of range
Temperature Range	Optional temperature probe
Power Supply	100-240V, 50/60Hz
Display	5-inch Color Touch Screen
Viscosity Range	1-2, 000, 000 cP
