Brookeld Engineering Labs., Inc. Page 6 Manual No. M13-167
All units of measurement are displayed according to either the CGS system or the SI system.
 1. Viscosityappearsinunitsofcentipoise(cP),Poise(P),milliPascal-seconds(mPa
•
s)orPascal-
seconds(Pa•s)ontheDV2TViscometerdisplayorcentistokes(cSt)ormillimetersquared
per second (mm
2
/sec).
 2. ShearStressappearsinunitsofdynes/squarecentimeter(D/cm
2
)orNewtons/square
meter (N/m
2
)/orPascals(Pa).
 3. ShearRateappearsinunitsofreciprocalseconds(1/sec).
 4. Torqueappearsinunitsofdyne-centimetersorNewton-meters(shownaspercent“%”in
bothcases)ontheDV2TViscometerdisplay.
5. Density appears in units of grams/cubic centimeter (g/cm
3
)orkilograms/cubicmeter
(kg/m
3
).
Note:TochangeCGStoSIunitsonthedisplay-seeSectionIV.3:GlobalSettings.
TheequivalentunitsofmeasurementintheSIsystemarecalculatedusingthefollowingconversions:
SI CGS
Viscosity: 1mPa•s = 1cP
ShearStress: 1Newton/m
2
= 10dyne/cm
2
Torque: 1Newton•m = 10
7
dyne•cm
ReferencestoviscositythroughoutthismanualaredoneinCGSunits.TheDV2TViscometerprovides
equivalentinformationinSIunits.
I.1 Components
Pleasechecktobesurethatyouhavereceivedallcomponents,andthatthereisnodamage.If
youaremissinganyparts,pleasenotifyBrookeldEngineeringoryourlocalBrookeldagent
immediately.Anyshippingdamagemustbereportedtothecarrier.
Components Part Number Quantity
DV2T DV2T Extra
DV2TViscometer varies 1 1
ModelGLaboratoryStand
Model Q Laboratory Stand
MODELG
MODEL Q
1
ø
ø
1
SpindleSetwithCase
DV2TLVsetoffourspindles
DV2TRVsetofsixspindles(#2-#7)
DV2THA/HBsetofsixspindles(#2-#7)
varies
SSL
SSR
SSH
1
or
or
1
For Cone/Plate versions: a spindle wrench (SP-23), one cone spindle (CPA-XXZ), a sample
cup (CPA-44YZ) replace the spindle set.
Power Cord
DVP-65for115
DVP-66for230
DVP-65
DVP-66
1
or
1
RTDTemperatureProbe DVP-94Y 1 1
GuardLeg
DV2TLV
DV2TRV
B-20Y
B-21Y
1
or
1
Carrying Case
PGFlashSoftware
RheocalcTSoftware
USBFlashDrive
ScreenClothw/case
Stylus
Operating Manual
ShippingCap
DVE-7Y
CD-PROGA
GV-3003
GV-1044
GV-1045
GV-1043
M13-167
N/A
1
1
ø
1
1
1
1
1
1
1
1
1
1
1
1
1

Brookfield DV2T Specifications

General

Type	Viscometer
Model	DV2T
Repeatability	±0.2%
Data Output	USB, RS-232
Accuracy	±1.0% of range
Temperature Range	Optional temperature probe
Power Supply	100-240V, 50/60Hz
Display	5-inch Color Touch Screen
Viscosity Range	1-2, 000, 000 cP
