Brookeld Engineering Labs., Inc. Page 35 Manual No. M13-167
TheResultsscreenincludesseveralNavigationIconsandCommandKeys.
Home: ReturntotheHomeMenu.
Down Arrow: SelectResultsOptions.
Blue Arrow: SelectPageofResultsTable.
Print: Print Data to USB printer.
Save: Save data.
CongureTest: ReturntoCongureViscosityTestscreen.
Scroll Bar: Moveup/downthroughapageofdata.
TheResultsscreenoffersseveraloptionsforviewingtestdata.Theseoptionsareaccessedviathe
DownArrowintheNavigationBaratthetopofthescreen(seeFigureIII-11).
Figure III-11
Table:Displayalldatapoints.Datawillbeshowninascrolllistwhereeachpagecanholda
maximumof50points.Ifthedatasethasmorethan50points,thenadditionalpages
willbeindicatedatthebottomofthescreen.Additionalpagesofdatacanbeaccessed
throughtheuseoftheBlueArrows

Brookfield DV2T Specifications

General

Type	Viscometer
Model	DV2T
Repeatability	±0.2%
Data Output	USB, RS-232
Accuracy	±1.0% of range
Temperature Range	Optional temperature probe
Power Supply	100-240V, 50/60Hz
Display	5-inch Color Touch Screen
Viscosity Range	1-2, 000, 000 cP
