Brookfield DV2T User Manual

Brookeld Engineering Labs., Inc. Page 65 Manual No. M13-167
Vane Spindles
Spindle Torque
Range
Shear Stress
Range (Pa)
Viscosity Range
cP (mPa·s)
V-71 NOT RECOMMENDED FOR USE ON LV TORQUE
V-72 LV .188-1.88 104.04-1.04K
V-73 LV .938-9.38 502-5.02K
V-74 LV 9.38-93.8 5.09K-50.9K
V-75 LV 3.75-37.5 1.996K-19.96K
V-71 RV .5-5 262-2.62K
V-72 RV 2-20 1.11K-11.1K
V-73 RV 10-100 5.35K-53.5K
V-74 RV 100-1K 54.3K-543K
V-75 RV 40-400 21.3K-213K
V-71 HA 1-10 524-5.24K
V-72 HA 4-40 2.22K-22.2K
V-73 HA 20-200 10.7K-107K
V-74 HA 200-2K 108.6K-1.086M
V-75 HA 80-800 42.6K-426K
V-71 HB 4-40 2.096K-20.96K
V-72 HB 16-160 8.88K-88.8K
V-73 HB 80-800 42.8K-428K
V-74 HB 800-8K 434.4K-4.344M
V-75 HB 320-3.2K 170.4K-1.704M
V-71 5XHB 20-200 10.48K-104.8K
V-72 5xHB 80-800 44.4K-444K
V-73 5XHB 400-4000 214K-2.14M
V-74 5xHB 4K-40K 2.172M-21.72M
V-75 5xHB 1.6K-16K 852K-8.52M
Note: 1.1Pa=10dyne/cm2
 2.ViscosityRangeisgivenatrotationalspeedof10RPM
 3.5xHBisthehighesttorquerangeavailable
 4.NotforusewithDV-EViscometers
M=1million
K=1thousand
Pa=Pascal
cP=Centipoise
mPa•s=Millipascal•seconds

Brookfield DV2T Specifications

General

Type	Viscometer
Model	DV2T
Repeatability	±0.2%
Data Output	USB, RS-232
Accuracy	±1.0% of range
Temperature Range	Optional temperature probe
Power Supply	100-240V, 50/60Hz
Display	5-inch Color Touch Screen
Viscosity Range	1-2, 000, 000 cP
