Brookfield DV2T - Accessory Calibration Procedures

Brookeld Engineering Labs., Inc. Page 74 Manual No. M13-167
Calibration Procedure for a Small Sample Adapter
Brookeldrecommendsatwostepcheck.First,verifythecalibrationoftheviscometerusingthe
standardviscometerspindles(LV#1-3,RV#2-6,HA#2-6andHB#2-6orcone/platespindles)
asdetailedinthisappendix.Second,verifythecalibrationoftheviscometerusingtheSmall
SampleAdapter.Theuseofanaccessorydevicemayincreasetheaccuracyofmeasurement
associatedwiththeDV2T.
WhenaSmallSampleAdapterisused,thewaterjacketisconnectedtothewaterbathandthe
waterisstabilizedatthepropertemperature:
1) Puttheproperamountofviscositystandarduidintothesamplechamber.Theamount
varies with each spindle/chamber combination (refer to the Small Sample Adapter
instructionmanual).
2) Placethesamplechamberintothewaterjacket.
3) Putthespindleintothetestuidandattachtheextensionlink,couplingnutandfree
hangingspindle(ordirectlyattachthesolidshaftspindle)totheDV2T.
4) Allow30minutesfortheviscositystandard,samplechamberandspindletoreachtest
temperature.
5) MeasuretheviscosityandrecordtheViscometerreading.Note: The spindle must rotate
at least ve (5) times before readings are taken.
Calibration Procedure for a Thermosel System
Brookeldrecommendsatwostepcheck.Firstverifythecalibrationoftheviscometerusingthe
standardviscometerspindles(LV#1-3,RV#2-6,HA#2-6andHB#2-6orcone/platespindles)as
detailedinthisappendix.SecondverifythecalibrationoftheviscometerusingtheThermosel.The
useofanaccessorydevicemayincreasetheaccuracyofmeasurementassociatedwiththeDV2T.
WhenaThermoselSystemisused, the controllerstabilizestheThermoContaineratthetest
temperature.
1) PuttheproperamountofHTviscositystandarduidintotheHT-2samplechamber.
Theamountvarieswiththespindleused(refertotheThermoselinstructionmanual).
2) PlacethesamplechamberintotheThermoContainer.
3) Putthespindleintothetestuidandattachtheextensionlink,couplingnutandfree
hangingspindle(ordirectlyattachthesolidshaftspindle)totheDV2T.
4) Allow30minutesfortheviscositystandard,samplechamberandspindletoreachtest
temperature.
5) MeasuretheviscosityandrecordtheViscometerreading.Note: The spindle must rotate
at least ve (5) times before readings are taken.
Calibration Procedure using UL or DIN Adapters
Brookeldrecommendsatwostepcheck.First,verifythecalibrationoftheviscometerusingthe
standardviscometerspindles(LV#1-3,RV#2-6,HA#2-6andHB#2-6orcone/platespindles)as
detailedinthisappendix.Second,verifythecalibrationoftheviscometerusingtheULorDIN
Adapters.Theuseofanaccessorydevicemayincreasetheaccuracyofmeasurementassociated
withtheDV2T.
