Brookeld Engineering Labs., Inc. Page 80 Manual No. M13-167
shouldbeknownthatthistypeoftorquereadingwillnotconvertintoacorrectcentipoisevaluewhen
usingaBrookeldfactoriftheboundaryconditionsarenotthosespeciedbyBrookeld.
TheguardlegisapartofthecalibrationcheckoftheBrookeldLVandRVseriesViscometer/Rheometer.
Ourcustomersshouldbeawareofitsexistence,itspurposeandtheeffectthatitmayhaveondata.
Withthisknowledge,theviscometerusermaymakemodicationstotherecommendedmethodof
operationtosuittheirneeds.
4 11/16
1 7/163 3/16
5 9/32
B-21Y
GuardLeg
ForRVTorque
B-20Y
GuardLeg
ForLVTorque
Figure F-1 - Brookeld Guard Leg
B-21KY
GuardLeg
ForRVTorque
B-20KY
GuardLeg
ForLVTorque
5 7/8
5 5/32
3 3/16
1 7/16
Figure F-2 - Brookeld EZ-Lock Guard Leg
