Brooks MT3809G - Model MT3809 and MT3810 Dimensional Drawings (MM;In) and Weights (Kg;Lbs) - Explosion Proof Housing

Installation and Operation Manual
X-VA-MT3809G-MT3810G-eng
Part Number: 541B182AAG
July, 2018
Models MT3809G & MT3810G
Figure 1-3 Model MT3809 and MT3810 Dimensional Drawings (mm/in) and Weights (kg/lbs) - Explosion Proof Housing
165 6.50
B
A
1.5[1/16]
D
172 6.75
C
165 6.50
B
A
1.5[1/16]
172 6.75
D
C
Model 3809 Explosion Proof Indicator Housing with
Flanged Connections mm [inches]
Model 3809 Explosion Proof Indicator Housing with
Threaded Female St'd Connections mm [inches]
* Dimensions apply to threaded female standard connections only.
Meter
Size
Connection A B C D Weight (Approx.)
0-5
7 & 8
10
12
13
1/2" Threaded Female St'd
1/2" Threaded Female St'd
1" Threaded Female St'd
1-1/2" Threaded Female St'd
2" Threaded Female St'd
225 [8.85]*
225 [8.85]*
300 [11.81]*
300 [11.81]*
300 [11.81]*
112 [4.41]
112 [4.41]
120 [4.73]
129 [5.08]
135 [5.31]
218 [8.57]
218 [8.57]
218 [8.57]
218 [8.57]
218 [8.57]
44 [1.72]
44 [1.72]
44 [1.72]
44 [1.72]
44 [1.72]
11.8 kg [26 lbs. ]
11.8 kg [26 lbs. ]
13.6 kg [30 lbs. ]
15.9 kg [35 lbs. ]
16.8 kg [37 lbs. ]
0-5
7 & 8
10
12
13
15
16
1/2" Flange
1/2" Flange
1" Flange
1-1/2" Flange
2" Flange
3" Flange
4" Flange
250 [9.84]
250 [9.84]
250 [9.84]
250 [9.84]
250 [9.84]
250 [9.84]
350 [13.78]
113 [4.45]
113 [4.45]
120 [4.73]
129 [5.08]
135 [5.31]
153 [6.02]
168 [6.61]
218 [8.57]
218 [8.57]
218 [8.57]
218 [8.57]
218 [8.57]
218 [8.57]
218 [8.57]
44 [1.72]
44 [1.72]
44 [1.72]
44 [1.72]
44 [1.72]
44 [1.72]
94 [3.69]
13.2 kg [29 lbs. ]
13.2 kg [29 lbs. ]
16.8 kg [37 lbs. ]
21.3 kg [47 lbs. ]
23.1 kg [51 lbs. ]
29.0 kg [64 lbs. ]
46.7 kg [103 lbs. ]
Meter
Size
0-51/2" Threaded Female 225 [8.85] 113 [4.45] 218 [8.58]41 [1.61] 11.8 kg [26 lbs. ]
1" Threaded Male 200 [7.87] 114 [4.49] 218 [8.58]28 [1.10] 11.8 kg [26 lbs. ]
7 & 81/2" Threaded Female 225 [8.85] 113 [4.45] 218 [8.58]41 [1.61] 11.8 kg [26 lbs. ]
3/4" Threaded Female 225 [8.85] 113 [4.45] 218 [8.58]41 [1.61] 11.8 kg [26 lbs. ]
1" Threaded Male 200 [7.87] 114 [4.49] 218 [8.58]28 [1.10] 11.8 kg [26 lbs. ]
10 1" Threaded Female 300 [11.81] 120 [4.72] 218 [8.58]78 [3.07] 13.6 kg [30 lbs. ]
1-1/2" Threaded Male 250 [9.84] 121 [4.76] 218 [8.58]53 [2.09] 13.6 kg [30 lbs. ]
12 1-1/2" Threaded Female 300 [11.81] 129 [5.08] 218 [8.58]78 [3.07] 15.9 kg [35 lbs. ]
2-1/2" Threaded Male 250 [9.84] 131 [5.16] 218 [8.58]53 [2.09] 15.9 kg [35 lbs. ]
13 2" Threaded Female 300 [11.81] 135 [5.31] 218 [8.58]78 [3.07] 16.8kg [23 lbs. ]
0-5 250 [9.84] 113 [4.45] 218 [8.58] 53 [2.09] 13.2 kg [29 lbs. ] - 15.6 kg [34 lbs. ]
7 & 8 250 [9.84] 113 [4.45]
218 [8.58]
53 [2.09]
13.2 kg [29 lbs. ] - 21 kg [46 lbs. ]
10 250 [9.84] 120 [4.72]
218 [8.58]
53 [2.09]
16.8 kg [37 lbs. ] - 23.6 kg [52 lbs. ]
12 250 [9.84] 129 [5.08] 218 [8.58] 53 [2.09] 21.3 kg [47 lbs. ] - 26.8 kg [59 lbs. ]
13 250 [9.84] 135 [5.31] 218 [8.58] 53 [2.09] 23.1 kg [51 lbs. ] - 37 kg [81 lbs. ]
15 250 [9.84] 153 [6.02]
218 [8.58]
53 [2.09]
29 kg [64 lbs. ] - 54 kg [119 lbs. ]
16 350 [13.78] 168 [6.61]
218 [8.58]
103 [4.06]
46.7 kg [103 lbs. ] - 67.7 kg [149 lbs. ]
Weight (Approx.)*
Flanged
(ANSI, DIN and JIS)
Connection A B C D
Model 3809 Explosion Proof Indicator Housing with
Threaded Female Connections mm [inches]
