3-2 Operation of the Model MT3809 Flowmeter with a Transmitter with or without Optional Alarms and
Pulse Output for Totalization
* Start-up the meter as described in Section 3-1.
* Programming performed prior to shipment (parameters).
The transmitter with or without alarms and pulse output is preprogrammed
prior to shipment for the following parameters based on the order
information, meter conguration and application. If parameters are not
specied in the customer purchase order, the defaults inherent to the
electronics will be as shown in (parenthesis).
Transmitter only Transmitter plus
pre-programmed parameters alarms and pulse output
preprogrammed parameters
Model Number Alarm LoLimit (0% FS ow)
Serial Number Alarm HiLimit (100% FS ow)
Tag Name (blank) Pulse output units (1 ppl)
Flow Rate units of measure (lpm) Resettable totalizer units of measure (lit.)
Low Flow cutoff (8% FS ow) Inventory totalizer units of measurement
(lit.)
Calibration factor (% scales only)
Analog Output LoRange
(4 mA @ 0% ow)
Analog Output HiRange
(20 mA @ 100% ow)
* Manual programming or reprogramming of the electronics.
Programming of the transmitter with or without alarms and pulse
output may also be done locally via an HART or Foundation Fieldbus
Communicator. Please refer to the manual of the communicator for
detailed description.
* Recalibration of transmitter output (spanning high and low)
At any time after factory calibration, shipment, installation, or service,
the transmitter can be recalibrated by overwriting any of the previous
calibration point-pairs, assuming that the user can provide a series of
accurate rates of ow through the meter. If preferred, the meter with
transmitter may be returned for recalibration at the Brooks service
department for a fee.
* Basic transmitter setup parameters
These are meter identication parameters set prior to shipment of the
meter.
Flowmeter identication: Model number, serial number, tag name.
Flowmeter conguration: Low ow cutoff, calibration factor, ow rate units
of measure.
Transmitter analog output: Analog output HiRange, analog output
LoRange.
* Optional programmable alarm and pulse output parameters and features
Alarm contact output: HiLimit, LoLimit
Latching or non-latching option shall be added for contact outputs.
