Mechanical
HART Transmitter
Foundation Field Bus
Transmitter
Inductive Alarm
Option
Enclosure
Type
M1 M2
M1 = Apparatus with Transmitter only
M2 = Apparatus with Inductive Alarm
Aluminum
9
9
9
9
Stainless
Steel
9
9
9
9
Stainless
Steel High
Temperature
9
9
9
9
Aluminum
9
9
9
9
Stainless
Steel
9
9
9
9
Stainless
Steel High
Temperature
9
9
9
9
Standards used for evaluation: (13ATEX0086X and IECEx DEK13.0027X)
EN 60079-0:2012+A11:2013, EN 60079-11:2012, EN 60079-15:2010, EN 60079-31:2014
IEC 60079-0:2011 modified + Cor.:2012 + Cor.:2013, IEC 60079-11:2011 + Cor.:2012, IEC 60079-
15:2010, IEC 60079-31:2013
Special conditions for safe use:
• In case the aluminium housing is mounted in an area where the use of EPL Gb (Category 2 G) or EPL
Gc (Category 3 G) apparatus is required, the transparent cover must be installed such, that ignition
sources due to electrostatic discharge sparks are excluded.
• In case the aluminium housing or painted housing is mounted in an area where the use of EPL Db
(Category 2 D) or EPL Dc (Category 3 D) apparatus is required, the transparent cover and the painted
parts must be installed such, that danger of ignition due to propagating brush discharges is excluded.
• For models marked with material code M, Titanium Grade II, the installation instructions contain the
specification of the alloy, allowing the user determine the suitability of the equipment for the particular
application.
• From the safety point of view the circuits shall be assumed to be connected to earth.
• On units with digital display the programming function through the LCD display shall only be done
outside the hazardous area.
• In case the surge protector is used in application with protection techniques Ex nA and Ex tc, the
surge protector shall be installed with a high strength locking compound on the mounting thread.
DEKRA 13ATEX0086X
IECEx DEK13.0027X
9
Unit without Digital DisplayUnit with Digital Display
II 2 G Ex ia IIC T4 Gb II 2 D Ex ia IIIC T135 °C Db
II 3 G Ex nA IIC T4 Gc II 3 D Ex tc IIIC T135 °C Dc
II 3 G Ex ic IIC T4 Gc II 3 D Ex ic IIIC T135 °C Dc
II 1 G Ex ia IIC T4…T3 Ga II 2 D Ex ia IIIC T135 °C…T200 °C Db
II 3 G Ex nA IIC T4…T3 Gc II 3 D Ex tc IIIC T135 °C…T200 °C Dc
II 3 G Ex ic IIC T4…T3 Gc II 3 D Ex ic IIIC T135 °C…T200 °C Dc
Declarations Mark
Meter Options
Standards/Directives/Marking Declaration/Certificate
Explosion safety
"Intrinsic Safety (ia)"
"Non-sparking (nA)"
"Enclosure Dust (tc)"
For temperature
limits, see Table:
Process and ambient
temperature limits
Intrinsic Safety / Non-
Sparking / Enclosure
dust
ATEX
IECEX
99
II 1 G Ex ia IIC T4…T2 Ga II 2 D Ex ia IIIC T135 °C…T300 °C Db
II 3 G Ex nA IIC T4…T2 Gc II 3 D Ex tc IIIC T135 °C…T300 °C Dc
II 3 G Ex ic IIC T4…T2 Gc II 3 D Ex ic IIIC T135 °C…T300 °C Dc
II 2 G Ex ia IIC T6…T4 Gb II 2 D Ex ia IIIC T85 °C…T135 °C Db
II 3 G Ex nA IIC T6…T4 Gc II 3 D Ex tc IIIC T85 °C…T135 °C Dc
II 3 G Ex ic IIC T6…T4 Gc II 3 D Ex ic IIIC T85 °C…T135 °C Dc
II 1 G Ex ia IIC T6…T3 Ga II 2 D Ex ia IIIC T85 °C…T200 °C Db
II 3 G Ex nA IIC T6…T3 Gc II 3 D Ex tc IIIC T85 °C…T200 °C Dc
II 3 G Ex ic IIC T6…T3 Gc II 3 D Ex ic IIIC T85 °C…T200 °C Dc
II 1 G Ex ia IIC T6…T2 Ga II 2 D Ex ia IIIC T85 °C…T300 °C Db
II 3 G Ex nA IIC T6…T2 Gc II 3 D Ex tc IIIC T85 °C…T300 °C Dc
II 3 G Ex ic IIC T6…T2 Gc II 3 D Ex ic IIIC T85 °C…T300 °C Dc
