<WSW26> (Function setting 4)
• Selector 3: Dialing during document reading into the temporary memory in in-
memory message transmission
If this selector is set to "0," the machine waits for document reading into the memory to
complete and then starts dialing. This enables the machine to list the total number of
pages in the header of the facsimile message.
• Selectors 4 and 5:No. of CNG cycles to be detected (when the line is connected via
the external telephone except in the external TAD mode or via the
built-in telephone)
The machine interprets a CNG as an effective signal if it detects the CNG by the number of
cycles specified by these selectors when the line is connected via the external telephone
except in the external TAD mode or via the built-in telephone.
Selector No. Function Setting and Specifications
1
2
Not used.
3
Dialing during document reading
into the temporary memory in in-
memory message transmission
0: Disable 1: Enable
4
5
No. of CNG cycles to be detected
(when the line is connected via
the external telephone except in
the external TAD mode or via the
built-in telephone)
In the case of Selector 3=0 in WSW54.
No. 4 5
00: 0.5 (A)
01: 1 (B)
10: 1.5 (C)
11: 2 (D)
In the case of Selector 3=1 in WSW54.
No. 4 5
00: 2.5 (A)
01: 3 (B)
10: 3.5 (C)
11: 4 (D)
6
7
No. of CNG cycles to be detected
(when the line is connected via
the external telephone in the
external TAD mode, via the built-
in telephone in the TAD mode, or
via the machine in the automatic
reception of the F/T mode)
In the case of Selector 6=0 in WSW58.
No. 6 7
00: 0.5 (A)
01: 1 (B)
10: 1.5 (C)
11: 2 (D)
In the case of Selector 6=1 in WSW58.
No. 6 7
00: 2.5 (A)
01: 3 (B)
10: 3.5 (C)
11: 4 (D)
8 Not used.
