<WSW31> (Function setting 9)
• Selector 2: Default reduction rate for failure of automatic reduction during recording
This selector sets the default reduction rate to be applied if the automatic reduction function
fails to record one-page data sent from the calling station in a single page of the current
recording paper.
If it is set to "0," the machine records one-page data at full size (100%) without reduction; if
it is set to "1," the machine records it at 70% size.
• Selector 5: Minimum ON and OFF duration of ringer signals effective in distinctive
ringing
The ringer pattern consists of short and long rings, e.g., short-short-long rings. This
selector sets the minimum ON and OFF duration of ringer signals that are required for the
machine to interpret ringer signals as being ON or OFF. This is to prevent components of
a ringer pattern from being misinterpreted due to chattering in distinctive ringing.
The machine monitors ringer signals at 10-ms intervals. If the signal is ON, the machine
counts +1; if it is OFF, it counts -1. If the counter increments up to +5 or +13 when this
selector is set to "1" (90 ms) or "0" (130 ms), respectively, the machine interprets the
current signal as being ON.
If the counter returns to zero, the machine interprets the signal as being OFF.
If the Distinctive Ring is set to OFF, this selector is not effective.
Selector No. Function Setting and Specifications
1 Not used.
2
Default reduction rate for failure
of automatic reduction during
recording
0: 100 % 1: 75 %
3 Not used.
4 (Do not disturb this selector.)
5
Minimum ON and OFF duration
of ringer signals effective in
distinctive ringing
0: 130 ms 1: 90 ms
6
I
7
Not used.
8 Drum life indication 0: No 1: Yes
Note:
• Selector 5 is applicable only to the U.S.A. models.
