App. 1-45
Confidential
<WSW45> (Speeding up scanning-2)
• Selectors 1 through 3:Delay time from when documents are set until the ADF starts
drawing them in
These selectors determine how long the ADF will delay automatic drawing-in of documents
(to the scanning standby position) after you set them in the ADF, as well as determining
whether or not the ADF automatically draws in documents.
• Selectors 4 through 6:
Periodical correction intervals of the reference voltage applied to
white level compensation for document scanning, during standby
These selectors set the correction intervals (in seconds) of the reference voltage to be
applied to white level compensation for document scanning during standby, as well as
determining whether or not the controller makes the reference voltage correction during
standby. (Conventionally, the correction has been made immediately before the start of
actual scanning)
This function takes effect in copying. Making the correction during standby may shorten
the preparation time for copying.
Selector No. Function Setting and Specifications
1
I
3
Delay time from when
documents are set until the ADF
starts drawing them in
No. 1 2 3
0 0 0: No automatic drawing-in
0 0 1: 1 sec.
0 1 0: 2 sec.
0 1 1: 3 sec.
1 0 0: 4 sec.
1 0 1: 5 sec.
1 1 0: 6 sec.
1 1 1: 7 sec.
4
I
6
Periodical correction intervals of
the reference voltage to be
applied to white level
compensation for document
scanning, during standby
No. 4 5 6
0 0 0: No correction of reference
voltage during standby
0 0 1: 10 sec.
0 1 0: 30 sec.
0 1 1: 1 min.
1 0 0: 3 min.
1 0 1: 5 min.
1 1 0: 10 min.
1 1 1: 30 min.
7
Standby position of the scanner
unit
0: Unit lock position
1:
Location of the white-level reference film
8
Line polarity reverse detection
function
0: No 1: Yes
Note:
• Do not access these selectors.
To Next Page
