App. 1-46
Confidential
• Selector 7: Standby position of the scanner unit
This selector determines whether the standby position of the scanner unit should be the
unit lock position or the location of the white-level reference film (attached to the inside of
the scanner top cover). If the location of the reference film is selected, the scanner unit will
not return to the home position so as to shorten the travel time, decreasing the preparation
time for copying.
• Selector 8: Line polarity reverse detection function
Line polarity will be reversed if the phone is hung up at the other end of the line. If this
selector is set to "1," the machine will detect the reverse polarity during an answering
machine operation and thereby determine that the phone has been hung up.
<WSW46> (Monitor of power ON/OFF state and parallel port kept at high)
• Selectors 1 and 2: Monitoring the PC ON/OFF state
For the related functions, refer to WSW36, selectors 2 and 3.
• Selector 4: Previous filtering parameters for white level compensation
At the start of scanning operation, the machine usually initializes white and black level data
stored in the EEPROM by scanning the while-level reference film attached to the inside of
the scanner top cover. After long use of the machine, however, the film may be
contaminated with dust or dirt.
Accordingly, incorrect white level data will be set up so that white vertical streaks will be
brought on the scanning result.
Setting this selector to "0" (Enabled) will apply previously saved white level data instead of
new incorrect compensation.
Selector No. Function Setting and Specifications
1
2
Monitoring the PC ON/OFF
state
No. 1 2
0 0: Disable
0 1: Monitor SELECT IN
1 0: Monitor STROBE
1 1: Monitor both SELECT IN and
STROBE
3
Parallel port output pins kept at
high level (Not used.)
4
Previous filtering parameters for
white level compensation
0: Enable 1: Disable
5
I
8
Not used.
Note:
• Selector 4 is not applicable to models equipped with flat-bed scanners.
